Biologically Inspired Underwater Robots for Three-Dimensional Collective Behaviors

The natural world abounds with self-organizing collectives, where large numbers of relatively simple agents use local interactions to produce impressive global behaviors. Such biological collectives exhibit several properties that are highly desirable from an engineering perspective: they are decentralized, providing robustness to failure of agents, and they rely primarily on local sensing and nearest neighbor interactions, exhibiting high degrees of scalability and adaptability.

Inspired by reef fish schools, the Blueswarm project aims to develop an experimental robotics platform for the investigation of self-organized collective behaviors in 3D space. To this end, we design, fabricate, and test miniature autonomous underwater robots with 3D vison-based perception and 3D fin-propelled locomotion.

We demonstrated 3D collective behaviors with Blueswarm using only vision-based coordination mediated through blue light. We showed that complex and dynamic 3D collective behaviors — synchrony, aggregation-dispersion, milling, search-capture, evasion — can be achieved through sensing minimalist and noisy impressions of the surroundings and without complete knowledge of neighbors. Our results provide new insights into the power of implicit coordination and are of interest for future underwater robots that display collective capabilities on par with fish schools for applications such as environmental monitoring and search in coral reefs and coastal environments.

Fish-Like Swimming and Schooling with an Autonomous and Biomimetic Robot

Fish are excellent swimmers, navigating cluttered environments such as coral reefs in search of food, migrating long distances in the ocean, or swimming up rivers to reproduce. In doing so, fish combine a high degree of maneuverability with effective long-distance swimming, a combination that is highly attractive from an engineering perspective. Fish can achieve this level of performance in part by using multiple fins to vector forces in three dimensions, supported by sensory systems for closed-loop control of fin kinematics.

We demonstrated fish-like swimming including properties such as U-shaped costs of transport and reverse Kármán wakes with a custom, more biomimetic version of our underwater robots named Finbot. We then used Finbot as a fish surrogate to experimentally validate a new thrust-based hypothesis on the hydrodynamic advantages of in-line schooling.

Dielectric Elastomer Actuators for Soft Robotics

Dielectric elastomer actuators (DEAs) are compliant capacitors that operate as soft electro-mechanical transducers and convert electrical energy into mechanical work. DEAs have several attractive properties compared to other smart materials, which make them particularly suitable for soft robotics applications. Unfortunately, most DEAs also have severe limitations including low output forces, the need for a rigid frame, high actuation voltages, slow response times, low energy density, and challenging integration with other components.

We were able to avoid pre-stretch of the elastomers, and multiply actuation forces by stacking several actuation layers. Such DEAs were strong enough to act as propulsive fins on an underwater robot in one of the first demonstrations of autonomous DEA-driven. We then explored soft DEA robots conducive to multi-modal locomotion. Our bending beam design approach enabled multiple gaits including crawling, hopping, jumping, and rolling. Gaits were selected and controlled by choice of actuation pattern, i.e., the frequency and magnitude of the applied input voltage to the DEA. Such DEA robots can be used as versatile experimental devices to validate locomotion models, in both natural and engineered systems.

Force Sensing Catheter for the Treatment of Cardiac Arrhythmia

Force Sensing Catheter is a medical device for the treatment of cardiac arrhythmia, during which the monitoring of contact forces applied to body tissue is critical. The ablation catheter has a miniscule diameter of 3.5mm and is suitable for in vivo applications. It uses a Hall sensor to infer axial and lateral contact forces. Such forces push on its flexible distal end during ablation and change the position of an embedded permanent magnet relative to the sensor. The resulting magnetic field is then translated to the corresponding forces, using a mapping found in simulation and during catheter calibration.

My Semester's thesis included the design, calibration, and validation of Force Sensing Catheter. In addition, I created a demonstration using the catheter to sample the texture and flexibility of tissue for diagnostic purposes.

Ship Inspection Robot for Semi-Autonomous Safety Inspection of Cargo Ships

Ship Inspection Robot (SIR) is a robust, cheap, and easy to operate inspection tool for the maritime transport sector. SIR can be operated while cargo ships are sailing, thereby reducing inspection time in dry docks. Thanks to its innovative overlapping wheel configuration, SIR is the first wheeled inspection robot that has the ability to overcome a broad variety of obstacles commonly encountered in cargo ships. Such obstacles include T-, L-, I-, and bulb-shaped stiffeners as well as convex and concave edges.

SIR was realized during a year-long Focus Project at ETH Zurich together with industry partner GE Inspection Robotics. I was leading the research team consisting of 10 interdisciplinary undergraduate students (6 mechanical and 2 electrical engineers, 2 industrial designers). For my Bachelor's thesis, I developed an Obstacle Climbing Controller for SIR, which reduced motor torque peaks inside obstacles by up to 40% and enabled smooth obstacle passing. The obstacle overcoming design aspects of SIR got patented internationally.
